Introduction
The LM-LUU is a widely used extended linear bearing designed according to metric standards. In its name, "LM" represents its Asian application, "L" indicates an extended structure, and "UU" signifies its double-seal feature. It consists of a cylindrical outer tube, an inner retainer with steel balls, and double-seal rings at both ends. The guide ring design of the retainer ensures smooth circulation of the steel balls, achieving low-friction linear motion through point contact between the balls and the shaft. It features high precision, low noise, and high rigidity, maintaining stable performance even under load. The bearing has a simple structure and high space utilization, making it adaptable to different operating environments.
Product Specifications
We offer a complete range of linear bearing products. For customized products, you can contact us.
Core Advantages
Lm Luu Linear Bearing feature high-quality materials for stability and durability. Its ST14 carbon steel outer ring (HRC58-62 after stamping and quenching) and GCr15 steel balls (roundness error ≤0.001mm) with nylon/glass fiber-reinforced cages reduce steel ball friction loss by 25% and ensure over 8000 working hours of service life.
Its material adaptability is excellent. With anti-rust coated outer ring and customizable temperature range (-20℃ to 120℃), nylon cages (noise ≤35dB) suit low-noise needs, while glass fiber-reinforced cages boost load capacity by 15% for heavy-load use.
It offers flexible customization: inner diameter 6-50mm, outer diameter 12-80mm, length 22-100mm, tolerance IT6-IT8, and repeat positioning accuracy ±0.01-±0.03mm, balancing precision and cost as needed.
Customization also covers load (40-200kg) and sealing (non-sealed, single/double-sealed). The double-sealed model (IP54 dust-proof) extends service life by 30% for harsh, dusty environments.
Application Range: LM-LUU linear bearings are widely compatible with 3D printers, CNC machines, and other equipment. They are also applicable to precision linear motion systems in semiconductor manufacturing, food packaging, industrial robots, and medical inspection fields.
Service Model
Standard Product Supply:
Offers in-stock products with delivery within 3-7 days;
Custom Solutions:
From requirement communication → solution design → sample testing → mass production, the entire process is supported by a dedicated technical contact;
After-Sales Support:
Provides product installation guidance, a 1-year warranty (excluding man-made damage), and rapid response service for malfunctions.
Our Factory
Xuxin Automation: Your Premier One-Stop Manufacturer for High-Precision Motion Components
we specialize in the R&D and manufacturing of custom non-standard lead screws and nuts. With our 13,000 m² state-of-the-art facility, we deliver highly reliable industrial automation solutions tailored to your exacting requirements.
Production Area
Advanced Equipment
Experienced Team
Annual Output
Why Choose Us?
Exceptional Non-Standard Customization Capabilities
In-house R&D: Our professional engineering team possesses decades of deep-seated expertise in the lead screw and nut industry.
On-Demand Development: Whether you require specialized leads, unique materials, or complex structures, we provide bespoke manufacturing based on your technical drawings (PDF, CAD, or 3D models).
Rigorous Quality Control & Manufacturing
High-Precision Machining: Leveraging our fleet of 80 CNC machines and precision grinding centers, we ensure every component achieves micron-level accuracy.
Full Supply Chain Integration: From raw material processing and heat treatment to precision grinding and final inspection, the entire process is completed in-house. This end-to-end control guarantees stable lead times and uncompromising quality.
FAQ
Q: Do linear bearings need lubrication? What is the commonly used lubricating medium?
Answer: metal linear bearings must be lubricated regularly, lubrication can reduce the friction and wear of the ball, optical shaft and jacket, reduce operating noise, and extend the service life; Only plastic self-lubricating linear bearings do not require additional lubricant refill. Commonly used lubricating media: Lithium soap-based grease (such as NLGI No. 2) is the main type, and low-viscosity lubricants can be selected for high-speed operation scenarios.
Q: What are the advantages of open linear bearings?
Answer: There is an axial slit on the jacket of open linear bearings, and the core advantage is that the mating gap can be adjusted. When the optical shaft and the bearing are too loose to fit and the accuracy is reduced, or the fit is too tight and the running lag is jammed, the bolt on the mount can be tightened and the bearing jacket can be squeezed to shrink, so as to fine-tune the mating gap between the bearing and the optical shaft to meet the needs of different working conditions.
Q: What should I pay attention to when installing linear bearings?
Answer: Focus on 3 points:
The matching optical shaft should be equipped with quenched G6 tolerance specification to ensure the accuracy of the fit;
The installation datum should be flat, and the coaxiality error between the bearing and the optical shaft should be controlled within 0.01mm to avoid stuttering or aggravated wear caused by tilted installation.
When press-fitting bearings, special tools should be used to apply evenly force, and it is forbidden to directly hit the bearing face or sealing ring to prevent damage to the components.
Q: What is the reason for the jamming or abnormal noise of linear bearings during operation?
Answer: There are 4 common causes:
Insufficient lubrication, the friction resistance between the ball and the optical shaft increases;
There are burrs, rust, or dust impurities on the surface of the optical shaft entering the bearing, scratching the balls or raceways;
The installation coaxiality error is too large, and the bearing is in oblique contact with the optical shaft.
The cage is deformed or the ball is damaged, resulting in poor ball circulation.
